Features

1. Fail secure, pulse to open
2. Elegant surface finish
3. Solid brass ball latch
4. Solid brass cylinder and deadbolt
5. Reliable locking mechanism 'Up to 1000000 operations'
6. High security, low noise
7. Certificate: CE, Rosh, CMA

Specification

• Image Sensor
  2 MP CMOS
• Signal System
  PAL/NTSC
• Frame Rate

  MJPG：

  1920 × 1080 @60fps/50fps/30fps/25fps

  1280 × 960 @60fps/50fps/30fps/25fps

  1280 × 720 @60fps/50fps/30fps/25fps

  640 × 480 @60fps/50fps/30fps/25fps

  640 × 360 @60fps/50fps/30fps/25fps

  YUV2：

  1920 × 1080 @5fps

  1280 × 960 @5fps

  1280 × 720 @10fps

  640 × 480 @30fps

  640 × 360 @30fps

• Resolution
  1920 'H' × 1080 'V'
• Min. Illumination
  0.1 Lux @ 'F1.2, AGC ON'
• Shutter Time
  PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
• Lens
  3.6 mm fixed focal lens
• Field Of View
  horizontal FOV: 87°, vertical FOV: 55°, diagonal FOV: 95°
• Lens Mount
  M8
• Day & Night
  24/7 Color Imaging
• Angle Adjustment
  pan: 0°; tilt: 0° to 90°; rotation: 0°
• Digital Zoom
  Yes
• Cable Length
  2 m
• Depth Of Field
  0.1 m to ∞

• Audio
• Audio Sampling Rate
  16 kHz

• Interface
• Video Output
  USB 2.0
• Audio In
  Built-in mic
• Operating System

  Windows XP/7/8/10

  Android 8.1+

  Linux 4.14+

  macOS 10.12+

  Chrome OS

• General
• Operating Conditions
  -10°C to 40°C, Humidity: 90% or less 'non-condensing'
• Power Supply
  DC 5V ± 5% 'USB'
• Consumption
  2.5 W MAX
• Dimension
  47.9 mm × 59.9 mm × 75.4 mm '1.89" × 2.36" × 2.97"'
• Approx. 169.5g '0.37 lb.'

• Accessory
• Packing List

  Camera × 1

  USB Cable × 1

  Quick Start Guide × 1

  Bracket × 1

  Tripod × 1

• 32 channels and 2 HDDs 1U DVR
• Efficient H.265 pro+ compression technology
• Encoding ability up to 1080p lite @ 15 fps
• 5 signals input adaptively 'HDTVI/AHD/CVI/CVBS/IP'
• Up to 18 network cameras can be connected

• 24 channels and 2 HDDs 1U DVR
• Efficient H.265 pro+ compression technology
• Encoding ability up to 1080p @ 15 fps
• 5 signals input adaptively 'HDTVI/AHD/CVI/CVBS/IP'
• Up to 32 network cameras can be connected

• 8 channels and 1 HDD 1U AcuSense DVR
• False alarm reduction by human and vehicle target classification based on deep learning
• Efficient H.265 pro+ compression technology
• Encoding abilty up to 8 MP @ 8 fps, 5 MP @ 12 fps
• 5 signals input adaptively 'HDTVI/AHD/CVI/CVBS/IP'
• Up to 16 network cameras can be connected.

Product Type

980 PCIe^® 3.0 NVMe^® SSD 500GB

Family Line

980 PCIe^® 3.0 NVMe^® SSD

Capacity

500GB

nterface

PCIe^® Gen 3.0 x4, NVMe^® 1.4

Speed

Read/write speeds up to: 3,100/2,600MB/s

Encryption

AES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive 'IEEE1667'

Sequential Read Speed

Up to 3,100 MB/s * Performance may vary based on system hardware & configuration

Sequential Write Speed

Up to 2,600 MB/s * Performance may vary based on system hardware & configuration

Cache Memory

HMB'Host Memory Buffer'

Reliability 'MTBF'

1.5 Million Hours Reliability 'MTBF'

• PANEL SIZE
  27" '69 cm'
• PANEL RESOLUTION
  2560 x 1440 'WQHD'
• REFRESH RATE
  165 Hz
• RESPONSE TIME
  1ms'MPRT'
• PANEL TYPE
  VA
• BRIGHTNESS 'NITS'
  250
• VIEWING ANGLE
  178°'H'/178°'V'
• ASPECT RATIO
  16:9
• CURVATURE
  1500R
• CONTRAST RATIO
  3000:1
• ACTIVE DISPLAY AREA 'MM'
  596.736'H' x 335.664'V'
• PIXEL PITCH 'H X V'
  0.2331 'W' x 0. 2331 'H'
• SURFACE TREATMENT
  Anti-glare
• DISPLAY COLORS
  16.7M
• DCI-P3 / SRGB
  92% / 115%
• VIDEO PORTS
  1x DP'1.2a'
  2x HDMI '2.0b'
• AUDIO PORTS
  1x Earphone out
• KENSINGTON LOCK
  Yes
• VESA MOUNTING
  100 x 100 mm
• POWER TYPE
  External Adaptor 20V 3.25A
• POWER INPUT
  100~240V, 50~60Hz
• DCR
  100000000:1
• SIGNAL FREQUENCY
  100000000:1
• NOTE
  Display Port: 2560 x 1440 'Up to 165Hz'
  HDMI: 2560 x 1440 'Up to 144Hz'
  *DCI-P3 and sRGB follow CIE1976 Standard

Panel Size 'inch' : 23.8
Aspect Ratio : 16:9
Display Viewing Area 'H x V' : 527.04 x 296.46 mm
Display Surface : Non-Glare
Backlight Type : LED
Panel Type : IPS
Viewing Angle 'CR≧10, H/V' : 178°/ 178°
Pixel Pitch : 0.2745mm
Resolution : 1920x1080
Brightness 'Typ.' : 250cd/㎡
Contrast Ratio 'Typ.' : 1000:1
ASUS Smart Contrast Ratio 'ASCR' : 80000000:1
Response Time : 5ms'GTG'
Refresh Rate 'Max' : 75Hz
Flicker-free : Yes

HDMI'v1.4' x 1
VGA x 1
Earphone Jack : Yes

• PANEL SIZE
  23.6" '60cm'

• PANEL RESOLUTION
  1920 x 1080 'FHD'

• REFRESH RATE
  144Hz

• RESPONSE TIME
  1ms

• PANEL TYPE
  VA

• BRIGHTNESS 'NITS'
  300 nits

• VIEWING ANGLE
  178° 'H' / 178° 'V'

• ASPECT RATIO
  16:9

• CURVATURE
  1500R

• CONTRAST RATIO
  3000:1

• ACTIVE DISPLAY AREA 'MM'
  521.3952'H' x 293.2848'V'

• PIXEL PITCH 'H X V'
  0.27156'H' x 0.27156'V'

• SURFACE TREATMENT
  Anti-glare

• DISPLAY COLORS
  16.7M

• DCI-P3 / SRGB
  90% / Up to 115%

• VIDEO PORTS
  1x DP
  2x HDMI '1.4'

• USB PORTS
  2x USB 2.0
  1x USB 2.0 Type B 'PC to Monitor'

• AUDIO PORTS
  1x Earphone out

• KENSINGTON LOCK
  Yes

• VESA MOUNTING
  100 x 100 mm

• CONTROL
  5-way OSD navigation joystick

• POWER TYPE
  Internal Adaptor

• POWER INPUT
  100~240V, 50~60Hz

• DCR
  100000000:1

• POWER CONSUMPTION
  28W

• SIGNAL FREQUENCY
  55.3 to 162KHz 'H'
  48 to 144Hz 'V'

• ADJUSTMENT 'TILT'
  -5° ~ 20°

• DIMENSION 'W X H X D'
  536.4 x 411.5 x 225.24 mm / 21.1 x 16.2 x 8.9 inch

• WEIGHT 'NW / GW'
  4.2kg / 6.4kg

• FRAMELESS DESIGN
  Yes

• COMPATIBILITY
  PC, Mac, PS5™, PS4™, Xbox, Mobile, Notebook
  * All trademarks and the registered trademarks are the property of their respective owners.

• NOTE
  Display Port: 1920 x 1080 'Up to 144Hz'
  HDMI: 1920 x 1080 'Up to 144Hz'
  The color gamut follows the CIE 1976 testing standard.

• OPERATING SYSTEM
  Windows 10 Home
  FREE Upgrade to Windows 11*

• CPU
  Intel® Core™ i7-11700F Processor 16M Cache, up to 4.90 GHz

• CHIPSET
  Intel® H510

• SYSTEM MEMORY
  32GB'16x2' DDR4 3200MHz U-DIMMs, up to 64GB

• VGA
  MSI GeForce RTX 3060Ti 8GB

• SOUND
  7.1 Channel HD Audio with Nahimic audio enhancer 'ALC897'

• STORAGE
  1TB M.2 2280 NVMe SSD 'SATA/PCIe Gen 3 x4 Combo'
  1x 2.5” Drive bays
  2 x 3.5” Drive bay

• WIRELESS LAN

  Intel® Wi-Fi 6E AX210 'optional'
• BLUETOOTH
  5.2

• I/O 'FRONT'
  1 x USB 3.2 Gen 1 Type C
  1x USB 3.2 Gen 1 Type A
  1x USB 2.0 Type A
  1x Mic-in
  1x Headphone-out

• I/O 'REAR'

  1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz
  1x VGA 'D-sub'
  1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz1
  4x USB 2.0
  1x PS/2 Combo Port
  2x USB 3.2 Gen 1 Type A
  1x RJ45 LAN
  3x Audio jacks
• LAN
  Intel WGI219V Gigabits LAN

• AC ADAPTER / PSU
  500W 80 Plus Bronze Certification PSU 'ATX'

• COOLING SYSTEM
  Air Cooler

• VOLUME
  42 Liter
• SOFTWARE
  Drivers & MSI Utilities
  Anti-Virus '60 days trial'
• FREE ITEM
  MSI VIGOR GK30 GAMING KEYBOARD
  MSI CLUTCH GM11 GAMING MOUSE

• Warranty
  02 Year

• OPERATING SYSTEM
  Windows 10 Home
  FREE Upgrade to Windows 11*

• CPU
  Intel® Core™ i5-11400F Processor 12M Cache, up to 4.40 GHz

• CHIPSET
  Intel® H510

• SYSTEM MEMORY
  16GB DDR4 3200MHz U-DIMMs, up to 64GB

• VGA
  MSI GeForce® GTX 1660 Super 6GB

• SOUND
  7.1 Channel HD Audio with Nahimic audio enhancer 'ALC897'

• STORAGE
  512GB M.2 2280 NVMe SSD 'SATA/PCIe Gen 3 x4 Combo'
  1x 2.5” Drive bays
  2 x 3.5” Drive bay

• WIRELESS LAN

  Intel® Wi-Fi 6E AX210 'optional'
• BLUETOOTH
  5.2

• I/O 'FRONT'
  1 x USB 3.2 Gen 1 Type C
  1x USB 3.2 Gen 1 Type A
  1x USB 2.0 Type A
  1x Mic-in
  1x Headphone-out

• I/O 'REAR'

  1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz
  1x VGA 'D-sub'
  1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz1
  4x USB 2.0
  1x PS/2 Combo Port
  2x USB 3.2 Gen 1 Type A
  1x RJ45 LAN
  3x Audio jacks
• LAN
  Intel WGI219V Gigabits LAN

• AC ADAPTER / PSU
  500W 80 Plus Bronze Certification PSU 'ATX'

• COOLING SYSTEM
  Air Cooler

• VOLUME
  42 Liter
• SOFTWARE
  Drivers & MSI Utilities
  Anti-Virus '60 days trial'

• FREE ITEM
  MSI VIGOR GK30 GAMING KEYBOARD
  MSI CLUTCH GM11 GAMING MOUSE

• Warranty
  02 Year

FEATURES

• Micro-Controller DSPIC Based Intelligent Control Design.
• Dual Charging, Mains Mode and Solar Mode. 'Solar Panel up to 1000W-12V model'.
• Pure Sine Wave Regulated Output.
• Smart PWM Controlled multistage ATM 'Automatic Trickle Mode' Charging.
• LCD and Graphical Display Indications 'Status & Fault'.
• Smart and Faster Overload Sense and Short Circuit Protection.
• Auto Reset Feature.
• Mains Input Voltage Range Selection.
• PV Mode ON/OFF Selection Switch.
• Charging Voltage Selection Switch.
• Grid Charging Enable /Disable Selection.
• Pure Sinewave Regulated Output.

KEY FEATURE

• Micro Controller Based Intelligent Control Design.
• LED Display Indications 'Status & Fault'
• CCCV Technology with Auto Trickle Mode
• Smart Overload Sense and Short Circuit Protection
• Battery State Monitoring
• Multi Stage Battery Charger
• Mains Input Voltage Range Slide Selection Switch



  Rated Capacity	2000 VA / 24V
  Output Power	1600 Watts
  Battery	2 Battery System '24 VDC'
  Waveform	Sinewave
  Warranty	06 Month

KEY FEATURE

• Hybrid Technology for Noiseless and Better Performance with Longer Backups & Battery Life.
• Battery Charging Current Selection Switch with Standard '10 Amps' & Fast Charging '14 Amps' Mode.
• IBGM Technology – Increases Battery Life and Performance by maintaining correct Battery Gravity.
• PWM Controlled Multistage ATM 'Automatic Trickle Mode' Charging.
• IN-Build Bypass Switch - Enables to isolate the UPS From Mains, whenever Needed.
• High & Standard Charging Option - For Quick Battery Charging.
• Unique Ultra Sonic Switching- For Noiseless Performance.
• Compatiable With all Battery Type - Tubular, Local & Flate Plate.



  Rated Capacity	1650 VA / 24V
  Output Power	1320 Watts
  Battery	2 Battery System '24 VDC'
  Waveform	Sinewave
  Warranty	06 Month

KEY FEATURE

• Micro controlled based Intelligent Control Design.
• Display Indications 'Status & Fault'.
• High Peak Current Handling Capability.
• High Voltage Surge Protection.
• Charging Mode, Load Type & Battery Type Selection Switches.
• Re-Settable Circuit Breaker.
• Smart Thermal Management Protection.



  Rated Capacity	1100 VA
  Output Power	825 Watts
  Battery	1 Battery System '12V'
  Wave form	Pure  Sinewave
  Warranty	06 Month

KEY FEATURE

• Hybrid Technology for Noiseless and Better Performance with Longer Backups & Battery Life.
• Battery Charging Current Selection Switch with Standard '10 Amps' & Fast Charging '14 Amps' Mode.
• IBGM Technology – Increases Battery Life and Performance by maintaining correct Battery Gravity.
• PWM Controlled Multistage ATM 'Automatic Trickle Mode' Charging.
• IN-Build Bypass Switch - Enables to isolate the UPS From Mains, whenever Needed.
• High & Standard Charging Option - For Quick Battery Charging.
• Unique Ultra Sonic Switching- For Noiseless Performance.
• Compatiable With all Battery Type - Tubular, Local & Flate Plate.



  Rated Capacity	1125 VA / 12V
  Output Power	900 Watts
  Battery	1 Battery System '12 VDC'
  Waveform	Sinewave
  Warranty	06 Month

• Detection Performance
• Detection Method : Opening Contact
• Detection Gap : 43mm Max



• Feature
• Digital Processing : Support
• Tamper Protection : Front;Rear
• Environment Temperature Indicator : Support
• Signal Strength Indicator : Support



• Interface
• Alarm Input : Normally Closed;Normally Open;Impulse Count
• Power Switch : Power Up Enrolling
• LED Indicator : Blue 'Alarm'



• Transmission
• Transmission Technology : Tri-X Wireless
• Transmission Method : Two-Way RF Wireless
• Transmission Frequency : 868MHz
• Transmission Security : AES-128 Encryption
• Transmission Range'Free Space' : 1.6Km
• Frequency Hopping : Support
• Enrolling Method : Power up;Remote ID;QR Code



• Electrical Characteristics
• Standard Battery Life : 5 years in work status 'being triggered 20 times per day'
• Power Supply : Battery Powered
• Battery Type : CR123A x 1
• Typical Voltage : 3V



• General
• Operation Temperature : -10 °C to 55 °C '14 °F to 131 °F'
• Storage Temperature : -20 °C to 60 °C '-4 °F to 140 °F'
• Operation Humidity : 10% to 90%

• Detection Performance
• Detection Method : Passive Infrared
• Detection Range : 15m
• Detection Angle : 85.9°
• Detection Zones : 52
• Detectable Speed : 0.3～2m/s
• Sensitivity : High;Auto;Pet
• Pet Immunity : 30Kg
• White Light Filter : 6500lux
• Digital Temperature Compensation : Support
• Creep Zone Protection : Support



• Feature
• Digital Processing : Support
• Sealed Optics : Support
• Tamper Protection : Front;Rear
• Environment Temperature Indicator : Support
• Signal Strength Indicator : Support



• Interface
• Power Switch : Power Up Enrolling
• LED Indicator : Blue'Alarm'



• Transmission
• Transmission Technology : Tri-X Wireless
• Transmission Method : Two-Way RF Wireless
• Transmission Frequency : 868MHz
• Transmission Security : AES-128 Encryption
• Transmission Range'Free Space' : 1.6Km
• Frequency Hopping : Support
• Enrolling Method : Power up;Remote ID;QR Code



• Electrical Characteristics
• Standard Battery Life : 5 years in work status 'being triggered 20 times per day'
• Power Supply : Battery Powered
• Battery Type : CR123A × 1
• Typical Voltage : 3V



• General
• Operation Temperature : -10 °C to 55 °C '14 °F to 131 °F'
• Storage Temperature : -20 °C to 60 °C '-4 °F to 140 °F'
• Operation Humidity : 10% to 90%

• Electrical characteristics
• Battery type : Battery 'default power supply method' or 12 VDC
• Power supply : Battery 'default power supply method' or 12 VDC
• Operation humidity : 10% to 90% 'no condensing'
• Operation temperature : -20 °C to 60 °C '-4 °F to 140 °F'
• Battery life span : 3 years in work status



• Wireless transmission
• RF frequency : 868 MHz
• RF modulation : 2GFSK
• RF distance : 1.6 km 'open area'



• General
• IP rate : IP65
• Installation method : Wall mounting
• Dimension : 'WxHxD'190× 200 × 47. 3mm .'7.48" ×7.87" × 1.86"）
• Shell material : PC+ABS
• 606.5 g '21.4 oz'

• Software features

• Tag : 32
• Area : 16
• Zones : 64 'up to 48 PIRCAMs'
• Installer : 1
• User : 30
• Admin : 1
• Voice Prompt : Supported
• Loudspeaker built in : Supported
• Memory Log stored : 5000
• Programming tools : Hik-Connect/Hik-ProConnect/Web Portal/ IVMS4200/ Convergence Cloud
• Firmware upgrade : APP/Web Portal
• Arm modes : Away/Stay
• Automatic Arm/Disarm Timers : Supported
• Forced Arming with Open Zones : Supported
• Diagnostics via the APP or Web : Supported
• ARC protocol

  SIA DC09'SIA level 2, Contact ID', ISUP, ISAPI 'SDK'

  Hik-IP Receiver & Hik-IP Receiver Pro 'Sur-Gard & Ademco 685'

  Supports video verification and remote control

• User APP for operating : Supported
• Installer APP for programming : Supported
• Web server for maintenance 'offline configuration' : Supported



• Hardware features

• RS232 output : Supported
• SIM slot : Single



• RF transmission

• RF Frequency : 868Mhz
• Wireless Security : Frequency Hoping 128 AES Encryption
• GPRS on board : Supported



• Electrical characteristics

• Power supply : Built in power supply
• Battery typeBuilt in on board Battery Li
• Battery life span : Up to 16 hours



• Wireless transmission

• Wired network: Supported
• Wi-Fi Standard : Supported



• Display

• LEDs Status : Arm/Disarm, Alarm, Tamper, Fault, Cloud, Power



• General

• Operation temperature : -10 °C to +55 °C
• Shell material : Plastic
• Dimension : 'WxHxD'170.0 mm '6.7"' x 170.0 '6.7"' mm x 38.6 mm '1.5"'
• 557.5 g : '19.7 oz'
• Color : White



• Device management

• Keyfob : 32
• Wireless sounder: 4 '2 internal+2 External'
• Keypad : 8 'Including Tag reader'
• Wireless Repeater : 2
• Multi Transmitter : 4
• PIR Cam : Supported

  Packege Incude


• · DS-PWA64-L-WE x 1
• · DS-PKF1-WE x 1
• · DS-PDP15P-EG2-WE x 1
• · DS-PDMC-EG2-WE x 1
